Zinc Oxide Plant

Name: Zinc Oxide Plant
Brand: U. M. ENGINEERING WORKS
Price: 2500000.0 INR
Availability: InStock

Price 2500000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Zinc Oxide Plant Specification

Motor Power
75-100 HP

Accessories
Cyclone Dust Collector, Bag Filter, Blower, Cooling Tower, Control Panel

Automation Grade
Fully Automated

Speed
Variable, up to 14 RPM

Temperature Range
900C to 1200C

Installation Guideline
Turnkey Installation & Commissioning Assistance Provided

Driven Type
Motor & Gearbox Driven

Efficiency (%)
Above 95%

Frequency
50-60 Hz

Usage & Applications
White Seal Zinc Oxide Production for Rubber, Paints, Ceramics, Pharmaceuticals, Electronics

Model No
ZO-PLT-2024

Production Capacity
Up to 6000 Tons/Year

Type
Zinc Oxide Plant

Material
S. S and Ms

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Controlled System

Drive Type
Electric

Voltage
380-440 V

Power
120-150 kW

Weight (kg)
35000-40000 kg

Dimension (L*W*H)
Customized as per project requirements

Color
white

Warranty
01 yer

Capacity
3-20 Tons/Day

Features
Continuous Operation, High Thermal Efficiency, Low Maintenance, User-Friendly Interface, Safety Interlocks

Machine Type
Rotary Kiln-based Zinc Oxide Production Plant

Power Consumption
Low Power Intake per Output Unit

Surface Finish
Anti-Corrosive Paint Finish

Raw Material
Zinc Dross, Pure Zinc, Zinc Scrap

Operational Mode
24/7 Continuous

Safety Features
Emergency Shutdown, Flameproof Controls, Heat Insulation

Startup Time
60-90 Minutes

Bag Filter Type
Pulse Jet Type

Noise Level
Less than 80 dB(A)

Furnace Body Thickness
Up to 30 mm

Chimney Height
As per Local Regulatory Norms

Cooling System
Closed Water Circuit

Dust Emission
Less than 30 mg/Nm3 (With Proper Filtration)

Service Support
On-site Technical Support & Operator Training

Blower Capacity
8000-12000 m3/hr

Heating Method
Gas Fired / Oil Fired / Coal Fired Options

Zinc Oxide Plant Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cheque, Telegraphic Transfer (T/T), Letter of Credit (L/C)

Main Domestic Market
All India

About Zinc Oxide Plant

A zinc oxide plant is an industrial facility that produces zinc oxide (ZnO), a versatile white powder used in numerous applications, including the rubber, ceramics, pharmaceuticals, and cosmetics industries. The production method and raw materials used determine the grade and purity of the final product

Advanced Heating and Energy Efficiency

The ZO-PLT-2024 is engineered for efficient zinc oxide production, offering gas, oil, or coal-fired heating options. Powerful blowers ensure optimal air flow, while the advanced rotary kiln design and closed water cooling system contribute to energy savings and stable thermal performance.

Superior Filtration and Emission Control

Equipped with a pulse jet bag filter and cyclone dust collector, the plant maintains dust emissions below 30 mg/Nm3, complying with strict local regulations. Chimney height is customizable as per regulatory standards, ensuring safe and eco-friendly operation.

Continuous, Automated Operation

Designed for 24/7 continuous operation, the plant is fully automated and PLC-controlled. Features like emergency shutdown, flameproof controls, and safety interlocks, along with variable speed drive and user-friendly touch interface, support reliable performance and minimal operator intervention.

Robust Construction and Customization

With a furnace body thickness up to 30 mm and anti-corrosive paint finish, the plant is built for durability. Dimensions and capacity-from 3 to 20 tons/day-are tailored to your project needs. Turnkey installation ensures a quick, seamless setup.

FAQ's of Zinc Oxide Plant:

Q: How does the Zinc Oxide Plant minimize dust emissions during operation?

A: The ZO-PLT-2024 uses a pulse jet type bag filter and cyclone dust collector system, which work together to keep dust emissions below 30 mg/Nm3. This system ensures compliance with environmental regulations and promotes a safer workplace.

Q: What heating methods are available for this Zinc Oxide Plant?

A: You can choose from gas, oil, or coal-fired heating options depending on local fuel availability and project requirements. Each option is supported by a robust rotary kiln system designed for high thermal efficiency.

Q: When and where is technical support provided for the installation and operation of the plant?

A: On-site technical support and operator training are provided during installation and commissioning at your chosen project location. Our expert team ensures smooth startup and hands-on training for ongoing operations.

Q: What materials can be used as raw input in this plant?

A: The plant processes zinc dross, pure zinc, and zinc scrap as raw materials, efficiently converting them into high-quality white seal zinc oxide suitable for various industries.

Q: What are the safety features integrated into the ZO-PLT-2024 plant?

A: Safety is prioritized through emergency shutdown systems, flameproof controls, comprehensive heat insulation, interlocks, and noise control strategies to maintain safe, reliable, and quiet operations.

Q: What is the main benefit of the plant's fully automated and PLC-controlled system?

A: The fully automated PLC control system ensures precise operations, energy efficiency, easy monitoring, and minimal manual intervention, leading to higher productivity and reduced operational errors.

Q: Which industries commonly use zinc oxide produced by this plant?

A: The zinc oxide produced here is widely utilized in rubber processing, paint manufacturing, ceramics, pharmaceuticals, and electronics, offering versatile applications across industrial sectors.
